HomeControllerLMLS-C3A2 4-Key Wireless RF Remote RGB LED Controller with Brake Light
HomeControllerLMLS-C3A2 4-Key Wireless RF Remote RGB LED Controller with Brake Light

Share：

LMLS-C3A2

LMLS-C3A2 4-Key Wireless RF Remote RGB LED Controller with Brake Light

AIDLITE Advanced Million Color LED Vehicle Control Box Upgrade allows you to maximize the impact of your Advanced Million Color Lighting Kit with a wide range of colors and lighting effects. Including 15 Solid Color Modes, 2 Color Cycle Modes, 3 Flashing Modes and 1 Fading Mode. The Blue Wire attached to the Control Box is for the Automatic Brake Lights feature, which illuminates all LED lights in red when using the brakes. Connect the wire to the motorcycle’s brake signal wires to activate. With a slim, low profile design, this control box upgrade can be easily installed under the seat or in the trunk of a car. All of the included featured colors and lighting patterns can be easily selected using the included f remote.

Specifications Description Photo
 Item No. LMLS-C3A2
 Voltage  DC 12V/24V
 Output Power  ＜180W (12VDC,24VDC)
 Output Current  12VDC 15A(max,) 24VDC 7.5A (max.)
 Controller size  60×40×15mm (LxWxH)
 Wireless Reomtes  2PCS

Applications
 Motor Vehicles
 Car / Motorcycle / Motorbike
 Classic cars / Golf cars / Toy cars
 Electric bicycle


*All specification/size listed are approximate, tolerance should be allowed.
*All specification and rating are subject to change without notice.
*ODM & OEM orders are welcome.
Voltage 6V/12V/24V DC
Vehicle Category Car
Application Universal
